MPU6050 (Digital Accelerometer & Gyro)

The MPU6050 is a serious piece of motion-tracking technology. It combines a 3-axis gyroscope and a 3-axis accelerometer on the same silicon die, together with an onboard Digital Motion Processor (DMP).

MPU6050 Sensor

Why use MPU6050?

  • Digital Interface: Uses I2C, allowing it to share the bus with other sensors like the DHT or LCD.
  • High Precision: Provides 16-bit resolution for each axis.
  • Integrated Gyroscope: In addition to vibration (acceleration), it can measure rotational movement and orientation.

Specifications

Parameter Value
Axes 6-axis (3 Accel, 3 Gyro)
Interface I2C
Accel Range ±2, ±4, ±8, ±16g
Gyro Range ±250, 500, 1000, 2000 °/s
Voltage 3V - 5V

Pinout

Pin Function ESP32 Connection
VCC Power 3.3V
GND Ground GND
SCL I2C Clock GPIO22
SDA I2C Data GPIO21
AD0 I2C Address Select GND (Address 0x68)

Code Example

#include <Adafruit_MPU6050.h>
#include <Adafruit_Sensor.h>
#include <Wire.h>

Adafruit_MPU6050 mpu;

void setup() {
  Serial.begin(115200);
  if (!mpu.begin()) {
    Serial.println("Failed to find MPU6050 chip");
    while (1) { delay(10); }
  }
}

void loop() {
  sensors_event_t a, g, temp;
  mpu.getEvent(&a, &g, &temp);

  Serial.print("Accel X: "); Serial.print(a.acceleration.x);
  Serial.print(" m/s^2, Y: "); Serial.print(a.acceleration.y);
  Serial.print(" m/s^2, Z: "); Serial.print(a.acceleration.z);
  Serial.println(" m/s^2");

  delay(500);
}

Troubleshooting

Issue Solution
"Failed to find chip" Verify I2C wiring (SDA/SCL) and ensure the module is powered.
Readings are static Ensure the module is not being held in a fixed orientation during test.
I2C Address conflict The default address is 0x68. Pull AD0 pin High to change to 0x69.
