ADXL335 (Analog Accelerometer)

The ADXL335 is a small, thin, low power, complete 3-axis accelerometer with signal conditioned voltage outputs. It measures acceleration with a full-scale range of ±3 g.

ADXL335 Sensor

Features

  • Analog Interface: Outputs voltage directly proportional to acceleration on X, Y, and Z axes.
  • Easy to Interface: Can be connected directly to the ESP32's ADC (Analog-to-Digital Converter) pins.
  • Low Power: Ideal for battery-powered environmental monitoring.

Specifications

Parameter Value
Axes 3-axis (X, Y, Z)
Output Analog Voltage
Sensitivity 300 mV/g (typical)
Range ±3g
Operating Voltage 1.8V - 3.6V (3.3V Recommended)

Pinout

Pin Function ESP32 Connection
VCC Power 3.3V
GND Ground GND
X X-axis analog out GPIO32 (ADC1)
Y Y-axis analog out GPIO33 (ADC1)
Z Z-axis analog out GPIO34 (ADC1)

Code Example

const int xPin = 32;
const int yPin = 33;
const int zPin = 34;

void setup() {
  Serial.begin(115200);
}

void loop() {
  int xRaw = analogRead(xPin);
  int yRaw = analogRead(yPin);
  int zRaw = analogRead(zPin);

  Serial.printf("X: %d | Y: %d | Z: %d\n", xRaw, yRaw, zRaw);
  delay(200);
}

Troubleshooting

Issue Solution
Noisy readings Add a 0.1μF capacitor between each output pin and GND.
Values don't change Check if the correct ADC pins are used; verify 3.3V power.
Constant max/min values Ensure the ESP32 and sensor share a common ground.
